Receptacles SCSI DB 100 female connector with latch bracket for PCB

Description : Starte Receptacles SCSI DB 100 female connector with latch bracket for PCB Clip Type, the scsi db 100 connector pin arrangement in two rows, one on top of the other. The top row has 50 pins and the lower row has 50 pins. Often used on the Industrial equipment PCB. Receptacles SCSI DB 100 female connector with latch for PCB Clip Type Item Receptacles SCSI DB 100 female connector with latch for PCB Clip Type Brand Starte Precision Electronics Co., Ltd No. Of Contact 100 pin Contact Type Female, receptacles connector for PCB Clip type Options Screw Bracket Threaded Finishes #2-56 Contact Finishes Gold Selective Plating PCB layout Standard   Materials of Receptacles SCSI DB 100 female connector with latch for PCB Clip Type: Housing: Plastic Thermoplastic Nylon PA9T UL94V-0, Black Connects: Copper Alloy Gold Selective Plated Front Shell: Steel, Nickel Plated Over Copper Bracket:Steel, Nickel Plated Over Copper Board Lock:Copper Tin Plated  Over Copper   Electrical Characteristics of Receptacles SCSI DB 100 female connector with latch for PCB Clip Type： Contact Current Rating: 1.0 Amp Dielectric Withstanding Voltage: 500V AC Insulation Resistance: ＞ 500MΩ/ Min Contact Resistance: 35mΩ /Max Operation Temperature:-55°C~ 85°C   Application: 1)motion controller, PCIx card 2)Servers machines and Drive enclosures equipments, 3)Mass storage machines,PCs and Macs and more peripherals 4)RAIDs,CD ROM,File Server board 5)Networking Equipments board 6)Small computer and intelligent peripherals,printers,hard disks,CD ROM drivers
