532nm 15mW Green Dot Laser Module for Stage Lamp/Lawn Lamp/Laser Positioning
$11.45
$22.79
532nm Green Dot Laser Module for Stage Lamp/Lawn Lamp/Laser Positioning The 532nm 15mW green laser module measures 13×22.5mm, operates at 2V, and is compact in size, capable of continuous operation for extended periods. At a distance of 10 meters, the spot size is 20mm. It is easy to install (with multiple angle options available). The 532nm green laser module features a clear beam, high brightness, and a sharp spot. Its compact and sturdy structure ensures good stability. It is suitable for applications such as indication and positioning, lawn lights, and stage lights. Core Specification : Wavelength 532nm Output Power 15mW Working Voltage 2V Beam Mode Dot beam Beam Size ≤20mm @10M Housing Size 13*22.5mm (Customizable) Lifespan 10,000 hours Product Display : Our Services : We have over 15 years of experience with Lasers. We offer professional OEM& ODM service for laser modules from 375nm to 1064nm! Item Parameter Wavelength 375-405nm 425-488nm 515-520nm 635-670nm 780-980nm Single Diode Module Optical Power 20mW-3W 20mW-3W 10mW-1.6W 5mW-2.5W 5mW-75W Multi Diodes Module Optical Power 3W-200W 6W-500W 1.6W-50W 2.5W-30W 75W-100W Operating Voltage 3-5V/6V/ 12V/ 24V/ 30V/ 110V/ 220V/ 240V etc. Beam Mode Dot/ Line/ Cross/ Grid/ Muti-lines/ DOE etc. Fan Angle Options of the Line Beam 5°/10°/15°/20°/25°/30°/45°/60°/90°/110°/130°/180° etc. Optical Lens Acrylic lenses, glass lenses, wave lenses, Powell lenses etc. Dimension 4*8mm/ 6*10.5mm/12*15mm/9*21mm/16*66mm/ 33*33*55mm/ Customizable etc. CDRH Class class1/class2/class3R/class3B/class4
Lighting Laser Module
